Cascade 38H PAPER ROLL CLAMP 3A OPENING 200 TO 1600MM CAPACITY 3600KG 38H-RCP-3A-0030 1057 mm

The Cascade 38H Paper Roll Clamp (Model: 38H-RCP-3A-0030) is a high-capacity forklift attachment designed for demanding paper handling operations including mills, stevedores, corrugators, converters, and large-scale printing facilities. With an arm opening range of 200 mm to 1600 mm and a maximum rated capacity of 3600 kg, this clamp delivers consistent, damage-free handling of large paper rolls, packaging rolls, and kraft stock across every application.

Built for the toughest industrial environments, the 38H series features Cascade's proven heavy-duty rotator drivetrain, ultra-thin arm and pad profile, and an advanced dual spring pad alignment system – ensuring every roll is handled with precision and zero damage from first grip to final placement. The 3A opening configuration provides versatility to handle a wide range of roll diameters without manual adjustment, making it ideal for high-cycle operations where speed and reliability are non-negotiable.

The 38H Paper Roll Clamp mounts to Class III–IV forklift trucks and is available with 360° or 180° rotation, giving operators full positional control even in tight warehouse aisles and container loading environments.

Key Features

Ultra-Thin Profile Pads – Specially designed pad geometry allows the clamp arms to knife between tightly stacked rolls in containers, trailers, and railcars without causing surface damage to the paper.

Dual Spring Pad Alignment System – New pad alignment technology using dual spring technology keeps contact pads in proper, consistent alignment during every clamp cycle, reducing wear and improving roll grip.

Heavy-Duty Rotator Drivetrain – High-torque rotator engineered for superior durability and proven performance in high-cycle, continuous shift operations.

High-Flow Revolving Connection – Provides fast arm speed for increased productivity. Also extends battery life on electric forklifts and reduces fuel consumption on internal combustion trucks.

Excellent Operator Visibility – Open arm structure design gives forklift operators a clear sightline through the arms, improving placement accuracy and safety.

360° or 180° Rotation Options – Allows operators to position rolls in any orientation, essential for loading and unloading vehicles from a single side.

Split Arm or Solid Arm Configuration – Choose the arm style that best suits your operation and the roll types being handled.

Positionable Short Arm with 45° Positioning – Short arm can be set to 45° to optimize handling for varied roll sizes and load configurations.

Optimized Pad Height – Pad dimensions are matched to maximize the usable range of roll diameters the clamp can safely grip.

Pad Protectors Included – Protects the contact pads from damage during transit and improves pad longevity in demanding applications.

Specifications

Model Number: 38H-RCP-3A-0030 Arm Opening Range: 200 mm to 1600 mm Rated Capacity: 3600 kg Mounting Class: Class III – IV Rotation: 360° or 180° (configurable) Arm Configuration: Split Arm or Solid Arm Short Arm Positioning: Fixed or Positionable at 45° Pad Type: Ultra-Thin Profile Pad Alignment: Dual Spring Technology Application: Mills, Stevedores, Converters, Corrugators, Printers, Warehouses Compatible Forklift Type: Internal Combustion and Electric Forklifts Brand: Cascade Corporation

Frequently Asked questions

1. What is the maximum capacity of the Cascade 38H Paper Roll Clamp?

 The Cascade 38H Paper Roll Clamp has a rated capacity of 3600 kg, making it suitable for handling large, heavy paper rolls in industrial mill, stevedoring, and warehouse applications.

2. What is the arm opening range of the 38H Paper Roll Clamp?

 The 3A configuration of the 38H Paper Roll Clamp provides an arm opening range of 200 mm to 1600 mm, allowing it to handle a wide variety of roll diameters without manual reconfiguration.

3. What types of forklifts is the Cascade 38H compatible with?

The Cascade 38H Paper Roll Clamp is compatible with Class III and Class IV forklift trucks, including both internal combustion and electric-powered models. The high-flow revolving connection is optimized to reduce battery drain on electric trucks.

4. What industries is the Cascade 38H Paper Roll Clamp designed for?

 This clamp is designed for use in paper mills, stevedoring operations, corrugating plants, print facilities, kraft and linerboard warehouses, and shipping/logistics operations that require high-cycle, damage-free paper roll handling.

5. Does the 38H Paper Roll Clamp come with rotation capability?

Yes. The Cascade 38H is available with either 360° or 180° rotation, giving operators the flexibility to position rolls in any direction required during loading, unloading, and storage operations.

6. How does the dual spring pad alignment system benefit operations?

 The dual spring technology keeps the contact pads in correct alignment throughout the clamping cycle. This reduces uneven wear on the pads, maintains a consistent grip on rolls, and minimizes the risk of roll surface damage during repeated handling.

7. Can the 38H clamp handle rolls inside containers or trailers?

 Yes. The ultra-thin arm and pad profile is specifically engineered to allow the clamp arms to knife between tightly packed rolls inside shipping containers, trailers, and railcars without damaging adjacent rolls.

8. Where can I buy or get a quote for the Cascade 38H Paper Roll Clamp in India?

 You can request a quote directly from MHE Bazar by visiting the product page at mhebazar.in or by contacting the sales team via phone or WhatsApp. MHE Bazar is an authorized supplier of Cascade forklift attachments in India with nationwide delivery.
